Function Description Setting options Factory settings
PR.INPUT Programmable input. Connection to terminal block X4 (9 + 10)
MOD1: PART UP button 1
When the button is pressed, the door opens as far as the intermediate
OPEN position (PART UP).
The door does not close automatically from the PART UP position.
MOD2: PART UP 1 switch
Closed: All OPEN commands lead to the PART UP position.
Open: All OPEN commands lead to the OPEN position.
The door closes automatically from both positions.
MOD3: PART UP 2 switch
Closed: All OPEN commands lead to the PART UP position.
Open: All OPEN commands lead to the OPEN position.
The door closes automatically from the PART UP position only.
MOD4: PART UP 3 switch
Closed: All OPEN commands lead to the PART UP position.
Open: All OPEN commands lead to the OPEN position.
The door closes automatically from the PART UP position only.
MOD1 – MOD11 MOD1
MOD5: PART UP 2 button
When the button is pressed, the door opens as far as the intermediate OPEN
(PART UP) position. The door closes automatically from the PART UP
position only.
MOD6: “Automatic closing” activation
Closed: Automatic closing deactivated
Open: Automatic closing activated
MOD7: External clock input
The door opens once the contact closes and remains in the OPEN
position until the contact opens. The door then closes automatically. This
function can be aborted by pressing the CLOSE button. The door CLOSES.
MOD8: Selector switch: Keeping the door open / alarm
Closed: The door moves to the PART UP position and remains
there as long as the contact is closed.
Open: Normal operation
MOD9: Continuously CLOSED signal 1
Closed: Door CLOSES with active safety devices and remains
in the CLOSED position until the contact opens. OPEN
commands are ignored. If the closing edge safety edge
(SKS) is triggered 3 times during the closing run, the
door remains in the OPEN position.
Open: Normal operation
MOD10: Continuously CLOSED signal 2
As MOD9, but after the closing edge safety device has triggered 3 times
and after a reversing movement of 750 ms, the door remains in the
position it was in.
MOD11: Selector switch: Keeping the door open / alarm
Closed: The door moves to the OPEN position and remains
there as long as the contact is closed.
Open: Normal operation
P/E BAR
CLOSE
Function of the photocell (X4 / 1-4) during the closing run.
MOD1: Stops the system when actuated
MOD2: Stop and reversal of the door system when triggered
MOD 1 – MOD 2 MOD 2
P/E BAR
OPEN
Function of the photocell (X4 / 1-4) during the opening run.
MOD1: Photocell not activated
MOD2: When the photocell is activated during the CLOSED end position and the
S-POINT2position,thedoorsystemstops.TheredtrafclightisON.The
S-POINT2 is automatically set to CLOSED end position + 600 inc.
MOD 1 – MOD 2 MOD 1
Overview of functions
