Function Description Setting options Factory settings
SKS LEADING Activation and connection of a leading photocell. The system replaces the conventional
closing edge safety device and is classed as an E device according to DIN EN 12453.
MOD1: No function
MOD2: MFZ-type leading photocell
Please note:
Only compatible with the leading photocell from MFZ.
Detailed information in the operating instructions for the leading photocell.
MOD 1 – MOD 2 MOD 1
Explanation of the relay modes:
A. Trafclightfunctions
MOD Description
CLOSED end
position
OPEN end
position
Prewarning Door run
MOD 1 Redtrafclight1 ON / OFF * OFF Flashing Lit up
MOD 2 Redtrafclight2 ON / OFF * OFF Flashing Flashing
MOD 3 Redtrafclight3 ON / OFF * OFF Lit up Lit up
MOD 18 Redtrafclight4 OFF OFF Flashing OFF
MOD 23
Greentrafclight OFF Lit up OFF OFF
* dependent on parameter MOD1-3 STAND
B. Position messages
MOD Description Remarks
MOD 6 OPEN end position The relay closes the contact when the door is at the OPEN end position.
MOD 7 CLOSED end position The relay closes the contact when the door is at the CLOSED end position.
MOD 8 Not OPEN end position The relay closes the contact when the door is not at the OPEN end position.
MOD 9 Not CLOSED end position The relay closes the contact when the door is not at the CLOSED end position.
MOD 10 Intermediate OPEN position (PART UP) The relay closes the contact when the door is at the intermediate OPEN position
(PART UP).
MOD 11 Intermediate CLOSE position (PART DOWN) The relay closes the contact when the door is at the intermediate CLOSE position
(PART DOWN).
MOD 12 Intermediate CLOSE position to CLOSED end position The relay closes the contact when the door is in the area between the CLOSED end
position and the intermediate CLOSE position (PART DOWN).
MOD 19 Intermediate OPEN position to OPEN end position The relay closes the contact when the door is in the area between the OPEN end
position and the intermediate OPEN position (PART UP).
