pro.point 8619470 - TIG TORCH PARTS; TIG Torch Assembly Overview

39
These parts are not original and are offered as replacement parts suitable for “TWECO” style torches.
©All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted by any means,
electronic, mechanical, photocopying or otherwise without the prior permission of ©Uniarc® the copyright holder.
Wear Parts Identification Next Page
Stubby series
Standard series
Gas Lens series
Large Gas Lens series
Stubby Gas Lens series
*
2
3
6
5
8
7
9
10
11
12
13
4
180A AIR COOLED TIG WELDING TORCH
Rating:180Amp DC, 125Amp AC @35% duty cycle.
tt
Description
12 Neoprene Cover X 3.2mt
Neoprene Cover X 7.2mt
13 Sheath X 12.5ft Inc Leather Cover
Sheath X 25ft Inc Leather Cover
Description
1 Torch head
Torch head flexible
2 Back cap long
3 Medium back cap
4 Short back cap
5 Momentary Kit
6 Trigger Lead 12.5ft
Trigger Lead 25ft
7 Screw Pack
8 Large Ergo Tig Handle
9 Large Knuckle Joint
10 Leather Cover X 0.8mt
11 Jointing Repair Kit
TIG Torch 8618456 Parts Breakdown
Sold Seperately
200 AMP Spool Gun Parts Breakdown
Part Number: 8612517
Sold Seperately
