pro.point 8619470 - Spare Parts Identification

46
1617
14
15
1820
19
10
11
13
12
9
21 22 23
24
# Description
Part Number
1 handle
2 front panel
3 Knob pointer
4 Knob pointer
5 Polarity lead
6 central adaptor
7 quick-connect 35-50
8 9 pin female socket
9 rear panel
10 power switch
11 gas inlet
# Description
12 fan DC24V
13 power cable
14 display pcb
15 plastic packaged solenoid valve
16 silicon bridge plate
17 Control pcb
18 wire feeder motor
19 mainboard
20 Insluation sheet
21 Spool holder
22 Selector switch
23 Wire inch & Gas check button
24 wire feeder motor
1
2
3
8
4
5
6
7
tt
Spare Parts Identification for
Pro.Point 145 & 180
