3 1/2 2A Mini Digital Clamp Meter user manual
11
Do not input the voltage which more than 600V DC.
1) Plug the black test lead into the COM jack and the red
test lead into the V/Ω Jack.
2) Set the rotary selector to V position to make the meter
get into DC V range.
3) Connect the test leads to the voltage source or load
terminals for measurement.
4) Take the reading on the LCD.
MEASURING AC CURRENT
WARNING
Beware of Electrocution.
Ensure that the test leads are disconnected from the
1) meter before making current clamp measurements. Set the
rotary selector to the A~2A/20A or 200A/400A range
position.
2) Press the trigger to open jaw. Fully enclose only one
conductor.
3) Take the reading on the LCD. MEASURING
RESISTANCE
WARNING
Beware of Electrocution.
Ensure that the test leads are disconnected from the meter
before making current clamp measurements.
1) Plug the black test lead into the COM jack and the red test
lead into the V/Ω Jack.
2) Set the rotary selector to Ω/ / range position to
make the meter get into AC V range.
