3 1/2 2A Mini Digital Clamp Meter user manual
12
3) Connect the test leads to the ends of the resistance or
circuit for measurement.
4) Take the reading on the LCD.
TESTING CONTINUITY
WARNING
Beware of Electrocution.
Make sure that the power of the circuit has been turned
off and the capacitors have been fully
discharged before testing the continuity of a circuit.
1) Plug the black test lead into the COM jack and the red test
lead into the V/Ω Jack.
2) Set the rotary selector to Ω/ / range position.
3) Press the “SEL” button to switch to continuity test.
4) Connect the test leads to the ends of the resistance or
circuit for measurement.
5) If the resistance of the circuit being tested is less than
50Ω, the built-in buzzer will sound.
6) Take the reading on the LCD.
TESTING DIODE
1) Plug the black test lead into the COM jack and the red test
lead into the V/Ω Jack.
2) Set the rotary selector toΩ/ / range position.
3) Press the “SEL” button to switch to test.
4) Connect the red test leads to the anode and the black test
lead to the cathode of the diode for testing.
5) Take the reading on the LCD.
TESTING TEMPERATURE
1) Plug the black test lead into the COM jack and the red test
lead into the V/Ω Jack.
