Pro'sKit MT-3102 - General Specifications

3 1/2 2A Mini Digital Clamp Meter user manual
4
FRONT PANEL DESCRIPTION
1. COM Input Jack / V/Ω Input Jack
2. 1/2-digit LCD Display Panel
3. Function Switch Button
(SEL/MAX/HOLD）
4. Function/range select rotary selector
5. Trigger
6. Protection edge
7. Current Clamp
LCD DISPLAY SYMBOLS
~ Alternating signal test
Direct signal test
Low Battery
Auto range mode ？
Diode test
Continuity buzzer
HOLD
℃/℉
Ω μm /
VA
MAX
This indicates that the display data is being held
Temperature test
Ohms, Kilo-ohms, mega-ohms resistance test
Amperes（Current）or Milli-volts, Volts（Voltage
）
The maximum value is being measured
－ Negative polar mark
GENERAL SPECIFICATIONS
1. Auto range and manual range options are available.
2. Over range protection is provided for all ranges.
3. Display：3 1/2-digit（1999 count）
AUTO
