ProAudio PP107233 - Specifications

ENGLISH
19
Tuner
FM Frequency Range 87.9 MHz — 107.9 MHz (200 kHz space)
Usable Sensitivity
(S/N = 26 dB)
8.2 dBf
(0.71 μV/75 Ω)
Quieting Sensitivity
(DIN S/N = 46 dB)
17.2 dBf
(2.0 μV/75 Ω)
Frequency Response (±3 dB) 30 Hz — 15 kHz
Signal-to-Noise Ratio (MONO) 64 dB
Stereo Separation (1 kHz) 40 dB
AM Frequency Range 530 kHz — 1 700 kHz (10 kHz space)
Usable Sensitivity
(S/N = 20 dB)
29 dBμ
(28.2 μV)
CD player
Laser Diode GaAIAs
Digital Filter (D/A) 8 times over sampling
Spindle Speed 500 rpm — 200 rpm (CLV)
Wow & Flutter Below measurable limit
Frequency Response (±1 dB) 20 Hz — 20 kHz
Total Harmonic Distortion (1 kHz) 0.01 %
Signal-to-Noise Ratio (1 kHz) 105 dB
Dynamic Range 90 dB
Channel Separation 85 dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
Auxiliary
Frequency Response (±3 dB) 20 Hz — 20 kHz
Input Maximum Voltage 1 000 mV
Input Impedance 30 kΩ
Specifications
USB
USB Standard USB 1.1, USB 2.0 (Full speed)
File System FAT12/16/32
Maximum Supply Current DC 5 V
1.0 A
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
WAV Decode Linear-PCM
FLAC Decode FLAC file (Up to 48 kHz/16 bit)
Audio
Maximum Output Power 50 W × 4
Full Bandwidth Power 22 W × 4 (at less than 1 % THD)
Speaker Impedance 4 Ω — 8 Ω
Tone Action Bass 100 Hz ±8 dB
Middle 1.0 kHz ±8 dB
Treble 12.5 kHz ±8 dB
Preout Level/Load 2 500 mV/10 kΩ
Preout Impedance ≤ 600 Ω
General
Operating Voltage
12 V DC battery
Installation Size (W × H × D) 182 mm × 53 mm × 158 mm
(7-3/16” × 2-1/16” × 6-1/4”)
Net Weight (includes Trimplate,
Mounting Sleeve)
1.3 kg (2.9 lbs)
Subject to change without notice.
