43
Specifications
The correlation between published specifications and sonic quality is unreliable. A
list of numbers reveals virtually nothing. All technical measurements must be sub-
ject to qualitative as well as quantitative interpretation.
Measurements of the CDP yield excellent results by any standards. However, only
those specifications that apply to its actual operation are included here.
■
Frequency response: 10 Hz – 20 kHz, +0dB, –0.2dB
■ Total harmonic distortion: 0.005% @ 1 kHz, A-weighted
■ Maximum output (XLR, fixed output mode): 4 V rms (0 dB output)
■ Maximum output (XLR, variable output mode): 8 V rms (0 dB output)
■ Maximum output (RCA, fixed output mode): 2 V rms (0 dB output)
■ Maximum output (RCA, variable output mode): 4 V rms (0 dB output)
■ Dynamic range: 98 dB (or better)
■ Signal to noise ratio (balanced outputs): 105 dB (ref: 0 dB output)
■ Channel separation: better than 110 dB
■ Analog filter: Bessel-tuned, linear phase to 40 kHz
■ Low-level linearity: deviation unmeasurable to below -70 dB
approximately +1.7 dB below -90 dB
(undithered, referenced to 0 dB @ 1 kHz)
■ Volume range: -116 dB to 0 dB
■ Volume resolution: 0.55 dB steps above 43 in display,
gradually increasing step size at lower levels
■ Digital inputs: 1 each s/pdif electrical (RCA) and EIAJ optical
■ Digital input impedance:75Ω (s/pdif electrical)
■ Other input:1
1
⁄8" mini-jack for external IR repeater
■ Digital output: 1 RCA (s/pdif)
■ Digital output impedance:75Ω (s/pdif electrical)
■ Analog outputs: 1 set balanced stereo outputs
1 set single-ended stereo outputs
■ Analog output impedance: less than 20Ω
■ Power consumption: less than 40 W
■ Mains voltage: 100V, 120V, 200V, 220V, 240V,
factory set for destination country only
■ Mains frequency: 50 or 60 Hz,
factory set for destination country only
■ Overall dimensions: See “Dimensions”
■ Shipping weight: 34 lbs. (15.5 kg)
For more information, see your Proceed dealer, or contact:
Madrigal Audio Laboratories, Inc.
P.O. Box 781, 2081 South Main Street
Middletown, Connecticut 06457 USA
Telephone (860) 346-0896 FAX (860) 346-1540
If purchased in the United States or Canada, the warranty on this Proceed
product is owner-transferable. If your product requires service, you must obtain
a Return Authorization before shipping it to Madrigal. Madrigal reserves the
right to repack any product which arrives improperly packed for shipment and
to charge the owner for the required packing material. For warranty
information and conditions on products purchased in other countries, contact
your local dealer or distributor.
