3.3.3.4 Test Conditions
To ensure proper hardness readings, the following conditions must be fulfilled. If one or more conditions are not met, the result may be misleading.
Probe setup HV1 (~10 N) HV5 (~50 N)
Minimal required thickness
5 mm / 0.2 inch
Minimal required weight
0.3 kg / 0.66 lbs
Required surface roughness
Grade class N8 N10
Maximum roughness 15 μm / 600 μinch 60 μm / 2400 μinch
Average roughness 3.2 μm / 125 μinch 12.5 μm / 500 μinch
Acceptable surface curvature
Radius > 3 mm
Minimum space
Indentation to edge 5 mm / 0.2 inch
Between indentations 3 mm / 0.12 inch
Indentation size on test surface
300 HV, 30 HRC
Depth 11.3 μm / 445 μinch 25.3 μm / 996 μinch
Diagonal 79.1 μm / 3114 μinch 177.1 μm / 6972 μinch
600 HV, 55 HRC
Depth 8 μm / 315 μinch 17.9 μm / 705 μinch
Diagonal 56 μm / 2205 μinch 125.3 μm / 4933 μinch
800 HV, 63 HRC
Depth 6.9 μm / 272 μinch 15.5 μm / 610 μinch
Diagonal 48.3 μm / 1900 μinch 108.5 μm / 4272 μinch
Table 4: UCI Test Piece Requirements
