© 2016 Proceq SA 47
12.4 Equotip Portable Rockwell Probe
Dimensions 112 x ø 40 mm (4.4 x ø 1.57 inches
without foot)
Weight 260 g (9.17 oz)
Power supply Via USB (5 V, max. 100 mA)
Measuring range 0-100 μm; 19-70 HRC; 34-1080 HV
Measuring accuracy 1.5 HRC according to DIN 50157
Resolution 0.1 μm; 0.1 HRC; 1 HV
Test direction Any direction (no correction required)
Test loads 10 N / 50 N (probe 50 N)
Diamond indenter Angle 100.0° ± 0.5°
Operating temperature 0 to 50°C (32 to 122 °F)
Humidity Non-condensing, 90% max.
12.5 Equotip UCI Probe
Dimensions 155 x ø 40 mm (6.1 x ø 1.57 inches) with-
out foot
Weight 270 g (9.52 oz)
Power Supply via Proceq Interface
Measuring Range 20 – 2000 HV
Measuring accuracy ± 2 % (150 – 950 HV)
Resolution 1 HV; 0.1 HRC
Test direction Any direction (no correction required)
Trigger loads Selectable: HV1 (~10N), HV2 (~20N),
HV3 (~30N), HV4 (~40N), HV5 (~50N)
Diamond indenter Vickers diamond according to ISO 6507-2
Operating temperature 0 to 50°C (32 to 122°F)
Humidity Non-condensing, 90% max.
13. Standards & Guidelines
• ISO EN 16859
• ISO 18265
• DIN 50156 / 50157 / 50159
• ASTM A956 / E140 / A370 / A1038
• DGZfP Guideline MC 1
• VDI / VDE Guideline 2616 Paper 1
• Nordtest Technical Report Series 424, Reports 99.12 / 99.13 / 99.36
• ASME CRTD-91
• GB/T 17394
• JB/T 9378
• JJG 747
• JIS B7731
