Proceq Equotip 550 User Manual

© 2016 Proceq SA 35
7. Information
Figure 25: Information Menu
7.1 Documents
All documentation files are stored in this section of the instrument and
can be viewed directly when required.
• Quick Start Guide: Gives an overview on the instrument including
scope of delivery.
• Operating Instructions: This document.
• Certificates: Certificates applicable to this product.
• Application Booklet: In-depth technical information on the different
measurement principles, its standards, influence of elevated tempera-
tures, heavy use instructions and more.
• Platform Remote Control Package: Instructions are given on how
the instrument can be used with the remote control, i.e. for automa-
tion etc.
• More documents may be added at a later date.
NOTE! The last viewed document can be quickly accessed
by pressing the “Soft Key”. For more information see chapter
“2.1 Installation”.
7.2 Upload PDF-Files from an USB-stick
Additional documents in the PDF format can be stored on the instrument.
To do so follow the steps below.
• Create the folder “PQ-Import” in the main directory of the USB-stick
(not as a subfolder in another folder) and fill it with all the pdf-files to be
uploaded to the Equotip Touchscreen
• Go to Information/Documents
• Connect the USB-stick to the USB Device plug on the left side of the
Equotip Touchscreen
• Click on
and confirm with click on
• The uploaded PDF-files appear on the bottom of the document list
NOTE! The USB stick must be either formatted in FAT or
FAT32. NTFS is not supported.
