To change a value, move the cursor under the number and scroll up/down to set a new value. Press
ENTER to save this value
Moisture = 12.89% 01
C1: 1.0
The first constituent will use the measure filter F1
and will thus have C1=1 and C6=0.0 the
coefficients for C2-C5 will variable, depending on
the application of the sensor.
Moisture = 12.89% 01
C2: 0.0
Oil = 25.8% 01
C1: 0.0
Pressing Display Rotate will show the coefficients
used by the second constituent. This algorithm
will use F6 as the measure filter so F1=0.0 and
F6=1.0. Again the coefficients for F2-F5 will
depend on the application.
Oil: 25.8% 01
C6: 1.0
Algorithm Math Treatment
The MCT is capable of using two styles of math treatment of the basic algorithm.
Linear: C1F1 …..+ C6F6
KC1F1 + K6F6
Log: Log C1F1….+ C6F6
K1F1 + K6F6
The MCT uses the linear math treatment as default.
The log treatment is used when the MCT is required to measure over very large ranges where the linear
treatment may give a slightly non-linear response. The log treatment will linearize the MCT response
and provide more accuracy in wide measurement applications.
Math Selection Codes
Selecting the following code makes selection of the desired math treatment:
49
To Next Page
