Moisture: 3.6% 01
Dead Band: 0.2
Dead Band
The MCT has built-in Smoothing
Factor that operates at a +/- level
either side of the sensor reading.
The default value is 0.2, the
minimum is 0.0 and the maximuim
is 1.0
Moisture: 3.6% 01
Enter for Reset
Reset
Press ENTER to RESET the
software. Customized settings will
not be altered.
To exit the Engineering Menu, press the LEFT arrow key TWICE
Appendix II – Powder Sampler Accessory
The MCT Powder Sampler is an accessory that allows the MCT sensor to make measurements on
products that are free falling inside enclosed ducts. It consists of a stainless steel tube, on the end of,
which is a sample cup complete with glass viewing window.
The sampler’s routine is controlled by s software routine in the sensor and an external solenoid valve.
The routine allows the cup to fill, the sensor to make and average reading the sample is then ejected
from the cup and the sequence repeats. A typical cycle time is 40 seconds
Installation
The sampler should be located in the process duct so that the sampler cup extends into the product flow.
Insertion Depth
The length of the welding spud supplied with the sampler determines the insertion depth of the sampler.
The following table gives the relationship between the length of the welding spud and the insertion
depth of the sampler.
Spud Len
th
(inches) (mm)
4.0 102
3.5 89
3.0 76
2.5 64
2.0 51
1.5 38
Insertion Depth
(inches) (mm)
4.0 102
4.5 114
5.0 127
5.5 140
6.0 152
53
