Main Menu Summary
Label Settings Description
U1 Sensor Type Used to select the type of sensor
U2 Signal Offset Offset -9 to +9 applied to reading
U3*,**Output Signal Offset Adjusts 4-20 mA output from -9 to +9
U4 Signal Filter Filter on input signals
U5 Set Point Dead Band (SP1) Value from 1 to 99, SP1
U6 Set Point Dead Band (SP2) Value from 1 to 99, SP2
U7 Power Save Set Point Value from 1 to 99, power save mode
U8 Display Stabilizer Stability when used with U4
L Set Point Limit High Set Point limit
F1 SP2 and U7 Disable Modifies control to single Set Point
F2 Heat/Cool Switch N/A
F3 Alarm Enable Enable the alarm Set Point
F4 Unit Display Enable Enable temperature units
F5 Temperature Unit Select °F or °C
F6* Current Output Enable Enable mA current
U1, Sensor Type
This setting tells the DQ15D control what type of sensor it is using.
Value/
Board # Sensor Type Sensor Description
1/5414 2-wire RTD Platinum RTD, TCR 0.00385 ohm/ohm/°C
2/5414 2-wire RTD Platinum RTD, TCR 0.00392 ohm/ohm/°C
3/5447* 3-wire RTD Platinum RTD, TCR 0.00385 ohm/ohm/°C
4/5447* 3-wire RTD Platinum RTD, TCR 0.00392 ohm/ohm/°C
5/5418** Thermocouple J-Type Iron-Constantan NIST Monograph 175 REV ITS-90
6/5418** Thermocouple K-Type Chromel-Alumel NIST Monograph 175 REV ITS-90
7/5418** Thermocouple T-Type Copper-Constantan NIST Monograph 175 REV ITS-
90
8/5418** Thermocouple R-Type Platinum, 13% Rhodium-Platinum NIST Monograph
175 REV ITS-90
9/5447* Voltage Potential signal (1.0 to 10.0 V)
10/5447* Current Current signal (4.00 to 20.00 mA)
11/5447* Frequency Pulse train frequency (0-200 Hz, counts/sec)
12/5447* Resistance Pure resistance signal (0 to 1000 ohms)
The 5447 sensor board will also accept 2 wire RTDs. The default sensor type setting is 1
(1000 ohm 2 wire RTD). When using the 5447 sensor board, an on-board DIP switch
must also be configured, see Dip Switch Settings.
*Optional 5416 sensor board permits 4-20 mA signal process value transmission.
