29200299-01D
1
2
3
4
6
5
7
ITEM MG2TIR MG3TIR MG2TIR-BB MG3TIR-BB DESCRIPTION QTY
1 161132-01 161562-01 161132-01 161562-01 Mounting Bracket 1
2 161133-01 161133-01 161133-01 161133-01 Piezo Ignitor 1
3 160960-01 160960-01 160960-01 160960-01 Cap with Seal 1
4 161142-01HT 161565-01HT 161142-01HT 161565-01HT Screen 1
5 * * 161555-01 161555-01 Left Support 1
6 * * 161554-01 161554-01 Right Support 1
7 * * MGB100 MGB100 Blower Assembly 1
PART AVAILABLE - NOT SHOWN
161607-01 161607-01 161607-01 161607-01 Hardware Package 1
161605-01 161605-01 161605-01 161605-01 Thermostat Bulb Clip 2
* Part is optional for this model.
PARTS
MODELS MG2TIR AND MG3TIR
MG2TIR-BB AND MG3TIR-BB
This list contains replaceable parts for your heater. When ordering replacement parts, follow
the instructions listed under Replacement Parts on page 27 of this manual.
MG3TIR-BB Shown
