Procom MG1TIR - Parts

www.usaprocom.com
200299-01D28
PARTS
MODEL MG1TIR
This list contains replaceable parts for your heater. When ordering replacement parts, follow
the instructions listed under Replacement Parts on page 27 of this manual.
ITEM MG1TIR DESCRIPTION QTY
1 161132-01 Mounting Bracket 1
2 161133-01 Piezo Ignitor 1
3 161528-01HT Screen 1
4 160960-01 Cap with Seal 1
PART AVAILABLE - NOT SHOWN
161607-01 Hardware Package
1
161605-01 Thermostat Bulb Clip 2
1
2
4
3
