24 PRODIGIT
PIN
Abbreviation
Description
Pin1 CD Carrier Detect
Pin2 RXD Receive
Pin3 TXD Transmit
Pin4 DTR Data Terminal Ready
Pin5 GND Ground
Pin6 DSR Data Set Ready
Pin7 RTS Request To Send
Pin8 CTS Clear To Send
Pin9 RI Ring Indicator
PC RS232 Port
