Auto-Sequence Example
In this example, we will create a program based on following Figure.
The program executes steps 1 to 8 in sequence.
Auto-sequence
Step number
Memory
BANK
Memory
STATE
Current
Value
Execution Time
(T1+T2)
1 3 1 1A 200mS
2 3 2 5A 200mS
3 3 3 1A 400mS
4 3 4 5A 400mS
5 3 5 1A 200mS
6 3 6 10A 200mS
7 3 7 1A 200mS
8 3 8 0A 200mS
