1.1 Features
The 3302F has the following key features:
1.1.1. Flexible Configuration: The 3302F can be used to house a variety of ‘F’
Series load modules with different voltage and current sink ranges.
1.1.2. Plug in Design: It is quick and easy to take a load module out of the
Mainframe and to replace it with another load module.
1.1.3. Computer Interfaces: GPIB,RS232, USB or LAN are optionally
Available for remote control. The mechanical design of the interface cards.
1.1.4. Front panel memory: Common test settings can be stored and recalled.
1.1.5. Auto Sequence: Memory locations can be linked to form a sequence
Against time.
1.1.6. Wake Up Function: The mainframe can be set to automatically revert to a
Load set up on mains power on.
1.1.7. Intelligent Cooling: Temperature controlled fans are used to minimise
1.2 Standard Accessories
The following accessories are provided as standard:
1.2.1. Model 3302F
1.2.2. BNC-BNC cable 1m
1.2.3. Model 3302F Operation Manual 1PC
1.2.4. 3Pin Power cable 1PC
1.3 Option
1.3.1. GPIB+RS232 interface
1.3.2. RS232 interface
1.3.3. GPIB interface
1.3.4. USB interface + USB DRIVER CD
1.3.5. LAN interface + LAN DRIVER CD
1.3.6. 9933 Remote Controller 1 PC
1.3.7. GPIB cable 1 M
1.3.8. GPIB cable 2 M
1.3.9. USB TYPE A TO TYPE B cable 1.8 M
1.4 Specifications
The specification of 3302F mainframe is shown below in Table 1-2.
TABLE 1-2 SPECIFICATIONS
LINE 100V/115V±10%
200V/230V±10%
FREQUENCY 50/60 HZ
FUSE
T1A/250V
(5*20mm)
T0.5A/250V
(5*20mm)
AC INPUT
MAX. POWER
CONSUMPTION
40 W
DIMENSIONS (W*H*D) 150 mm*177 mm*445 mm
WEIGHT NET : 5.5 Kg
