3302F Series Mainframe Operation Manual 55
4.6.3. STATE functions can be used to see the actual operating status of the electronic
Load at that time.
[STATe
：
] LOAD {SP}{ONOFF}
Command Syntax:
[STATe：] LOAD{SP}{ONOFF}{；NL}
[STATe：] LOAD ？{；NL}
Purpose: Read LOAD ON/OFF status
Description: This command is used to see if the Load is ON or OFF
0 = Load OFF
1 = Load ON
[STATe
：
] MODE {SP}{CCCRCVCPLED}
Command Syntax:
[STATe：] MODE {SP}{CCCRCVCPLED}{；NL}
[STATe：] MODE ？{；NL}
Purpose: Set and read the operating mode of LOAD
Description: The return value is 0│1│2│3│4 which corresponds to the
Operating mode that the load is in. i.e. CC│CR│CV│CP │LED
CC CR CV CP LED
Mode
(value)
(0) (1) (2) (3) (4)
331XF V V V V
333XF V V V V
334XF/G V V V V V
33401F/G V V V V
TABLE 4-9 MODULES FOR EACH SERIES
[STATe
：
] SHORt {SP}{ONOFF}
Command Syntax:
[STATe：] SHORt {SP}{ONOFF}{；NL}
[STATe：] SHORt ？ {；NL}
Purpose: Reads back whether the short circuit test is active or not
Description: 0 = short circuit test active
1 = short circuit test inactive
