TECHNICAL SPECIFICATIONS
IV.1 Dimensions & Weight
 Width: 210mm; Height: 42 mm; Depth: 173 mm.
 Weight: 500 g.
IV.2 Power Supply
 1x VDC input 90V to 264V
 Connector plug Ø5.5 x Ø2.5 x 11mm.
IV.3 User interface
 1x capacitive touch panel 95 x 55mm (optional).
 1x remote web control.
 Front power on/off.
 LED status indication for alarm and power-on.
IV.4 Audio inputs /outputs
 Analog or digital stereo inputs/outputs with XLR connectors.
IV.5 Communication
 1x Control Ethernet port (10/100/1000BaseTx Ethernet, RJ45 connector).
 1x Streaming Ethernet port (10/100/1000BaseTx Ethernet, RJ45
connector).
 2x USB ports (Host 2.0 with maximum 500mA current supply)
 1x RS232. RJ45 connector.
 BRAVE protocol with bonding or diversity.
