DSO26 User Manual
40
23 TFL115SP + SAT 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Sat Out 5 Sat
Out 3 Aux Out 6 Aux
Sub PRL1400
24 TFL115SP + 10P BA 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Low Out 5 Low
Out 3 High Out 6 High
Sub PRL1400, Low PRL600, High PRL600
25 TFL115SP + 12P BA 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Low Out 5 Low
Out 3 High Out 6 High
Sub PRL1400, Low PRL950, High PRL600
26 TFL115SP + 15P BA 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Low Out 5 Low
Out 3 High Out 6 High
Sub PRL1400, Low PRL1400, High PRL600
27 TFL118SP + SAT 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Sat Out 5 Sat
Out 3 Aux Out 6 Aux
Sub PRL1400
28 TFL118SP + 10P BA 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Low Out 5 Low
Out 3 High Out 6 High
Sub PRL1400, Low PRL600, High PRL600
29 TFL118SP + 12P BA 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Low Out 5 Low
Out 3 High Out 6 High
Sub PRL1400, Low PRL950, High PRL600
30 TFL115SP + 15P BA 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Low Out 5 Low
Out 3 High Out 6 High
Sub PRL1400, Low PRL1400, High PRL600
31 TFL115SP + 152P BA 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Low Out 5 Low
Out 3 High Out 6 High
Sub PRL1400, Low PRL1400, High PRL600
