DSO26 User Manual
37
FACTORY PRESETS
DSO26 is factory preloaded with presets for the EDGE and TFL loudspeaker lines.
The presets were optimized by engineers at Proel to achieve the best performance.
As a general rule Sat and Aux outputs are not locked and can be programmed by users to
fulfill their needs. All Aux outputs are muted by default.
Sub out gain is trimable, its limiter thresholds are generally left free and the delay time is
unlocked. The default time alignement was calculated in Proel’s anechoic chamber taking
into account the most common speaker placement positions.
No Preset Name
10 EDGE121SP+212P A
11 EDGE218SP+212P A
12 EDGE121+218+212A
13 EDGE121SP+212P B
14 EDGE218SP+212P B
15 EDGE121+218+212B
16 Sub+EDGE15CXP BA
17 EDGE121SP + SAT
18 AUX + TFL10 BA
19 AUX + TFL12 BA
20 AUX + TFL15 BA
21 AUX + TFL152 BA
22 AUX + TFL212 BA
23 TFL115SP + SAT
24 TFL115SP + 10 P BA
25 TFL115SP + 12 P BA
No Preset Name
26 TFL115SP + 15 P BA
27 TFL118SP + SAT
28 TFL118SP + 10 P BA
29 TFL118SP + 12 P BA
30 TFL118SP + 15 P BA
31 TFL118SP + 152P BA
32 TFL215SP + SAT
33 TFL215SP+12P BA
34 TFL215SP+15P BA
35 TFL215SP+152P BA
36 TFL215SP+212P BA
37 TFL218SP + SAT
38 TFL218SP+15P BA
39 TFL218SP+152P BA
40 TFL218SP+212P BA
Note: Always check Proel website http://www.proelgroup.com for updates.
EDGE presets
There are two versions of EDGE presets, A and B. These differ in the high frequency
shelving presets. Version A is suited for indoor applications or when EDGE 212P are not
arrayed. Version B is for outdoor applications or when EDGE 212P are arrayed, resulting
in a better dispersion pattern.
10 EDGE121SP+212P A 2x3 way crossover
Out 1 Sub Out 4 Sub
Out 2 Mid Out 5 Mid
Out 3 High Out 6 High
Allowed Sub gain trim and delay time; normal High shelving eq.
11 EDGE218SP+212P A 2x3 way crossover
Out 1 Low Out 4 Low
Out 2 Mid Out 5 Mid
Out 3 High Out 6 High
Allowed Low gain trim and delay time; normal High shelving eq.
