10
11. STEREO DELAY 2 - Echo e ect characterized with a long me.
12. HALL+DELAY - Combina on of two of the previous presets.
13. ROOM+DELAY - Combina on of two of the previous presets.
14. VOCAL+DELAY 1 - Combina on of two of the previous presets, reverb with short tail and a long delay.
15. VOCAL+DELAY 2 - Combina on of two of the previous presets, reverb with a long tail and a mono delay.
16. REV+CHORUS - Typical vocal reverb and chorus e ect combined together, useful to simulate more instruments
playing together, works well on vocals, guitars, strings, woodwinds.
21. POWER switch
Switch this one on and the unit has power. Make sure that all MAIN knobs are turned all the way down when powering
up or down.
22. PWR indicator
Indicates when the unit is switched on.
23. AC~ SOCKET
Here’s where you plug in your mains supply cord. You should always use the mains cord supplied with the device. Be
sure that your device is turned o before you plug the mains supply cord into an electrical outlet.
24. FUSE holder
Here is where the mains protec on fuse is placed.
REPLACE THE PROTECTION FUSE ONLY WITH SAME TYPE AS SHOWN ON THE PRODUCT.
IF AFTER THE SUBSTITUTION, THE FUSE INTERRUPTS AGAIN THE APPARATUS WORKING, DO NOT TRY AGAIN
THEN CONTACT THE PROEL SERVICE CENTER.
25. LINE VOLTAGE selector
This switch sets the AC voltage line of your country (usually it is set by factory and isn't necessary to change it). The 115V
se ng is for mains line in the range of 105-120V~ and 230V se ng is for mains line in the range of 210-240V~.
WARNING: an incorrect se ng of AC LINE VOLTAGE could damage seriously the internal electronics!
