MIXER SECTION SEZIONE MIXER
MONO channels (3) MIC/LINE input (XLR/JACK combo) Canali MONO (3) ingresso MIC/LINE (XLR/JACK combo)
STEREO channels (1) LINE input (2 x RCA) Canali STEREO (1) ingresso LINE (2 x RCA)
Input Channel EQ HIGH: +/-15dB 10 kHz, LOW: +/- 15dB 100 Hz Equalizzatori Ingressi ALTI: +/-15dB 10 kHz, BASSI: +/- 15dB 100 Hz
Phantom power + 15 V (CH 1-3) Alimentazione Phantom + 15 V (CH 1-3)
Eect processor 24 bit digital - 16 Preset Processore eeo 24 bit digitale - 16 Preset
Eect presets HALL, ROOM, VOCAL and PLATE reverbs,
DELAY, REV + DELAY, REV +CHORUS
Impostazioni eeo riverberi HALL, ROOM, VOCAL e PLATE,
DELAY, REV + DELAY, REV +CHORUS
MONITOR out 1 x 3/4" jack Uscita MONITOR 2 x JACK 6,3mm
STEREO LINE out 2 x RCA Uscita STEREO LINE 2 x RCA
Main EQ 3-band EQ (HIGH, MID & LOW) EQ Main EQ 3-bande (HIGH, MID & LOW)
POWER OUT 1 x 3/4" jack (speaker 4 ohm min) Uscita SPEAKER 1 x jack 6,3mm (altoparlante min 4 ohm)
Metering 4-LED VU-METER Misurazione Livello 4-LED VU-METER
AMPLIFIER SECTION SEZIONE AMPLIFICATORE
Connuous Power 75 W @ 4 ohm (1 KHz, 1% THD) Potenza Connua 75 W @ 4 ohm (1 KHz, 1% THD)
Maximum Power 150 W @ 4 ohm (1 KHz, 1% THD) Potenza massima 150 W @ 4 ohm (1 KHz, 1% THD)
LOUDSPEAKER SECTION SEZIONE ALTOPARLANTE
System 2 Way - Vented Box Sistema 2 Vie - Bass Reex
Low Frequency Device 6.5” woofer with 1" VC Altoparlante Bassi 6.5” woofer con 1" VC
High Frequency Device 1” neodymium tweeter Altoparlante Al 1” neodymium tweeter
Angular Coverage 90° H x 60° V Copertura Angolare 90° O x 60° V
Impedance 4 ohm Impedenza nominale 4 ohm
Frequency Response 75 Hz - 20 kHz (-6 dB) Risposta in Frequenza 75 Hz - 20 kHz (-6 dB)
Max SPL 110 dB SPL massima 110 dB
Construcon MDF with black anscratch paint, metal grille Costruzione MDF colore nero angrao, griglia metallica
Pole holder 1 oponally aachable at boom or at side Flangia per supporto 1 opzionale collegabile soo o al anco
GENERAL SPECIFICATION SPECIFICHE GENERALI
Power Supply 230 V~ / 120 V~ (switchable) 50/60 Hz Alimentazione 230 V~ / 120 V~ (commutabile) 50/60 Hz
Consumpon 180 W Assorbimento 180 W
Dimensions (W x H x D) 200 x 320 x 220 mm Dimensioni (L x A x P) 200 x 320 x 220 mm
Weight 6.2 kg (13.7 lb) Peso 6.2 kg
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
