PROEL PRL250 - PRL250 Connectors and Specifications; Technical Specifications for PRL250

15
CONNETTORI - SPECIFICHE TECNICHE
CONNECTORS - TECHNICAL DATA
CONECTORES - ESPECIFICACIONES TECNICAS
PRL250
SPECIFICHE TECNICHE Italiano TECHNICAL DATA English ESPECIFICACIONES TECNICAS Español
43.8 mm
32.5mm
374 mm
384mm
483mm
436mm
32.5mm
RCA-pin unbalanced
positive / ground
JACK balanced
Tip-positive / Ring-negative / Sleeve-ground
JACK unbalanced
Tip-positive / Ring-negative connected
to Sleeve-ground
CONNETTORI Italiano CONECTORES EspañolCONNECTORS English
POWER CONNECTOR
1+ / 1- connected
2+ / 2- not connected
Misure di potenza effettuate secondo le norme AES.
Power measurements refer to AES standards.
Medidas de potencia realizadas en conformidad con las normas AES.
PRL250
Output power (THD<1% 1kHz)
Stereo 8+8Ω 80W+80W
Stereo 4+4Ω 125W+125W
Bridge Mono 16Ω 125W
Bridge Mono 8Ω 250W
Frequency response (± 0.5dB) 20Hz-20kHz
Input sensitivity: 0dB
Input impedance: 20kΩ balanced / 10kΩ unbalanced
Damping factor: >300 @ 4Ω
S/N ratio: (unweighted) >100dB
Input connectors: Stereo Jack
1
/
4
” and RCA-pins
PRL250
Output connectors: SPK4MP (1+/1-) and Binding posts (Bridge)
Cooling: convection
Indicators (LED) Green/Red for Signal/Clip - Red for Protect
Protections: DC - Thermal - Soft Start - Short circuit
OSC™ Output Sense Clipping
Power supply 230V AC - 50Hz or 117V AC - 60Hz
Mains fuse T2A 230V / T4A 117V
Max power consumption 500VA
Dimensions: WxHxD 483x43.8x384mm
Weight: 9.5kg - 21lbs
Shipping: 10.4kg / 0.037cbm
