INTRODUCTION
ThankyouforchoosingthisPROELproductandforyourtrustinourbrand,synonymousofprofessionalism,
accuracy, high quality and reliability. All our products are CE approved and designed for continuous use in
professionalapplications.
DESCRIPTION
Inresponse totheincreasingrequestfor compact, lightweightandeasy ‐to useportablePA systems, PROEL
introduces the WAVE series, a new range of active speakers featuring multiple inputs and a versatile MP3
playerwithBLUETOOTHconnectivity.Hostedinlightweightyetultra‐durablepolypropylenecabinets,WAVE
systemscombineselected
HFandLFtransducerswithstateoftheartelectronics,includingasophisticated
pre‐ampsectionwithactivefilteringanddualCLIPLIMITERSand efficientClassDpoweramplifiersfortheLF
section.
TheMEDIAPL AYERyoucanfindon‐boardisabletoplayfromanSDcardor
aUSBMEMORYSTICK,butalso
thruaBLUETOOTHconnection.YouonlyneedtopairyoursmartphoneoryourtabletwithaWAVEspeaker
forplayingmusicwithouttheneedofanycable.
Thanks to the built‐in 2‐channel mixer you can connect a microphone or an additional external
source to
yourPAandmixyoursoundwithindependentlevelcontrolsanda2‐bandEQ.
ThethreemodelsoftheWAVEseriescanbeusedinavarietyofapplications,rangingfromspeechdiffusion
andmusicplaybacktolivemusicandDJsets.Theextremelyversatilecabinetscan
bemountedonstandard
speaker poles, laid on the side  for the use as stage monitors and even suspended using the built‐in flying
points.
MAINPANELOPERATIONS

1. MIC/LINEIN(XLR)
ThisisafemaleXLRconnectorthatacceptsaXLRplugfromanybalancedorunbalanceddynamic
microphoneorlineleveldevice.TheXLRinputiswiredasfollows:
Pin1=shieldorground
Pin2=+positiveor"hot"
Pin3=‐negative
or"cold"
