SYSTEM OWNER’S MANUAL
Pro Flo 800 SL
Pro Flo 800 SL System Diagram
8
550 Gals. or larger
Pretreatment
Chamber
75% to 100%
Daily Hydraulic
Capacity
MINIMUM
DIMENSIONS
Inside Width ................ 55”
Inside Length .............. 40”
Water Level ................. 57”
Minimum Length to Width Ratio: 1 to 1
Inlet
*Actual Scaled Weight
Pretreatment Tank Sold Separately
Pump Tank Sold Separately (Not Shown)
Drawing Not to Scale All Gallonage Approximate
Warning Light
913 Gal.
Aeration Chamber
Air
Diffuser
304 Gal.
Clarifier
Mute Switch
Outlet
Clarifier
Access
Aerator Cover
Aerator
Outlet
Baffle
#/4” PVC
Pipe
45°
Slope
Control
Panel
SPECIFICATIONS
Overall Length............... 101#/4”(t) - 99!/4”(b)
Overall Width ......................... 68”(t) - 64”(b)
Height without Risers ............................ 71”
Exterior Wall Thickness ........................... 3”
Interior Wall Thickness .............. 2”(t) - 3”(b)
Top Thickness ......................................... 5”
Bottom Thickness .................................... 3”
Aeration Length............... 64!/2”(t) - 63 !/2”(b)
Clarifier Length ............... 29!/4”(t) - 26#/4”(b)
Water Level ........................................... 55”
Air Diffuser ............................................ 27”
Bottom of Inlet to Bottom of Tank ....... 60 !/2”
Total Tank Weight (Empty) ....... 13,010* lbs
(t) = Top Dimension - (b) = Bottom Dimension
Configurations may vary.
Pro Flo 800 SL GPD Unit
NOTE: If the wall between the Clarifier and Aeration
Chamber is a drop-in wall, the thickness shall be 2!/2”
Solids
Deflector
16” Clarifier
Riser
20” Aeration
Riser
