profluid PF70-30DFS - Safety Precautions and System Considerations; SAFETY PRECAUTIONS


Rev.20170601 V1.0E HPC INSTALLATION & OPERATION MANUAL 4
MODEL
PF 70-30 DFS (SFS)
Main Power
3Ph 220Vac 50/60Hz
Motor
3Ph 220/380Vac 50/60Hz
7.5KW 27.6/26.1A
RequiredInlet Pressure [Bar(PSI)]
1.2~4.1(17~59)
MaxiumDischarge
Pressure [Bar(PSI)]
70 (1015)
Volume 50/60Hz [LPM(GPM)]
24(6.3) / 30(7.9)
Discharge Fitting
1/2"(-12)JIS37
INLET Hose Fitting
1"
DRAIN Hose Fitting
3/4"
Orifice[mm]
2.46
Dimensions [mm]
835 x 736 x 1339H
Ship Weight [Kg]
295
Ship Weight [Kg]
표준
Table 1
Note : Dual rated motor may be operated at 60Hz or 50Hz
Motor RPM and Discharge volume will be different
Volume = Discharge volume + Bypass volume
SF - Filter 1 ea , DF - Filter 2 ea
Section Ⅱ - Safety Precautions and System Considerations
SAFETY PRECAUTIONS:
・ Read and follow all instructions and safety warnings in this manual prior to installing or operating this high
pressure system.
・ Always wear safety glasses when operating high pressure.
・ Have all machine guards in place before activating high pressure.
・ Never put any part of your body in front of the coolant stream.
・ Never adjust Pressure Regulating Valve in increase coolant pressure without a properly sized discharge orifice
installed(Table 1 Reference).
・ Adjust coolant nozzles only when the system is not in operation.
・ Never direct the coolant stream at any person.
