9
6. Press a Base Cap (82) into the Base (85).
82
8
5
6
7. With the help of a second person, carefully tip
the treadmill onto its right side. Partially fold the
Frame (48) so that the treadmill is more stable;
do not fully fold the Frame yet.
Attach a Wheel (86) to the Base (85) with an
M10 x 50mm Bolt (27) and an M10 Nut (33). Do
not overtighten the Nut; the Wheel must turn
freely.
7
85
86
27
48
33
