9
10. Make sure that all parts of the elliptical exerciser are properly tightened. Place a mat under the elliptical
exerciser to protect the floor or carpet from damage.
9. The Console (23) requires three 1.5V “AAA” batteries;
alkaline batteries are recommended. Slide off the
Battery Cover (29) and press the batteries into the
battery clip; make sure that the negative (“–”) ends
of the batteries are touching the springs in the
battery clip.
Reattach the Battery Cover.
9
8. Find the Left Pedal (13), which has a ridge on the
r
ight side. Attach the Left Pedal to the Left Pedal Arm
(11) with three M4 x 19mm Flange Screws (36) as
shown.
A
ttach the Right Pedal to the Right Pedal Arm (not
shown) in the same way.
11
8
13
36
23
29
