ProForm 490 Le Elliptical User Manual

6
1.
While another person lifts the Base (1),
a
ttach the Front Stabilizer (6) to the Base
with two M10 x 80mm Carriage Bolts (82)
and two M10 Locknuts (81).
2. Remove the indicated screw and the ship-
ping bracket from the Base (1). Discard the
screw and the shipping bracket.
Next, tighten the Base Foot (26) into the
Base (1).
6
81
81
82
1
1
Shipping
Bracket
26
Screw
2
1
To make assembly easier, read the
information on page 5 before you
b
egin.

ProForm 490 Le Elliptical Specifications

General

Brand	ProForm
Model	490 Le Elliptical
Category	Elliptical Trainer
Language	English
