ProForm 5.2 Treadmill User Manual

1
1
13. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear
plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread-
mill. Note: Extra hardware may be included. Keep the included hex keys in a secure place; the large hex key
is used to adjust the walking belt (see pages 23 and 24).
12. Raise the Frame (56) to the position shown.
H
ave a second person hold the Frame until
this step is completed.
Orient the Storage Latch (53) so that the large
b
arrel and the Latch Knob (54) are oriented as
shown.
Attach the Latch Bracket (109) and Storage Latch
(53) to the Base (83) with two 3/8" x 2" Bolts (4)
and two 3/8" Nuts (8).
Attach the upper end of the Storage Latch (53)
to the bracket on the Frame (56) with a 3/8" x 2"
Bolt (4) and a 3/8" Nut (8). Note: It may be nec-
essary to move the Frame back and forth to
align the Storage Latch with the bracket.
Lower the Frame (56) (see HOW TO LOWER
THE TREADMILL FOR USE on page 21).
53
8
8
Large
Barrel
83
4
56
109
1
2
4
54

ProForm 5.2 Treadmill Specifications

General

Brand	ProForm
Model	5.2 Treadmill
Category	Treadmill
Language	English
