6
6. Remove the backing from the Adhesive Clip (98).
Press the Adhesive Clip onto the base of the Uprights
(71) in the indicated location. Press the Allen Wrench
(99) into the Adhesive Clip.
71
99
98
6
6. Make sure that all parts are tightened before you use the treadmill. To protect the floor or carpet, place a
mat under the treadmill. To order a mat, see the back cover of this manual.
5. Attach the Frame Guide (5) and the two Frame Guide
Spacers (116) to the left side of the Frame (1) with two
Small Screws (4) as shown. Be careful not to over-
tighten the Screws. Make sure that the thick end of
the Frame Guide is at the bottom.
Note: If it is difficult to fold or lower the treadmill,
remove one or both of the Frame Guide Spacers
(116).
5
1
4
116
Thick End
5
4. With the help of a second person, carefully raise the
Uprights (71) until the treadmill is in the position
shown.
71
4
To Next Page
