11
8. If there are four screws (B) in the locations
shown, remove and discard them.
8
B
B
9. Note: If assembled on a smooth surface, the
treadmill may roll forward during this step.
Raise the Frame (56) to the upright position.
IMPORTANT: Do not raise the Frame past the
vertical position. Have a second person hold
the Frame until step 11 is completed.
Orient the Latch Crossbar (38) as shown. Make
sure that the “This side toward belt” sticker
(C) is facing the treadmill. Attach the Latch
Crossbar to the brackets on the Frame (56) with
two 5/16" x 3/4" Screws (25) and two 5/16" Star
Washers (11).
56
38
C
11
11
25
25
Brackets
9
To Next Page
