7
2. Remove the indicated screw and the ship-
ping bracket from the Base (1). Discard the
screw and the shipping bracket.
Next, tighten the Base Foot (26) into the
Base (1).
Shipping
Bracket
26
Screw
2
1
3. Attach the Rear Stabilizer (7) to the Frame
(2) with two M10 x 127mm Screws (83).
Next, hold the handle on the Frame (2),
press the Latch (68), and lower the Frame
until the Rear Stabilizer (7) rests on the floor.
3
83
7
Handle
2
68
To Next Page
