STEP 2C – PERMANENT HARD WIRING

ItispossibletohardwiretheDCchargingleadstothebatteryforpermanentinstallations.

TheDCleadsarepre-wiredwithcablelugstomakethisprocesseasier.

Itisrecommendedtofitacircuitbreakerorinlinefusewiththefollowingratings.(Seebelow)

IC2500&IC2500W=30Amp

IC3500=50Amp

IC5000=100Amp

IC800-24=12Amp

Connection:

1. UnscrewandremovethebatteryclipsfromtheDCleadsusinga4mmallenkey.

Note:Thesebatterychargersincludesensorwiresthatrunparalleltoboththe

positiveandthenegativeDCleads.Thisallowsforaccuratevoltagemeasurements

tobetakendirectlyfromthebattery.ItisstronglyrecommendednottocuttheDC

leadsduringinstallation.HoweveriftheDCleadsarecut,ensurethatthesensor

wiresareincludedinbothpositiveandnegativeconnections.

2. ConnectacircuitbreakerorinlinefusetotheREDPositive(+)lead(includesensor

wireifDCleadhasbeencut).

3. Connectashortcabletotheotherendofthecircuitbreakerorinlinefuse&connect

tothePositive(+)batterypost.

4. ConnectthecablelugfittedtotheBLACKleadtotheNegative(-)batterypost

(includesensorwireifDCleadhasbeencut).

5. Fitthecorrectlyratedfuse(inlinefuseapplicationsonly).

IfthechargerisusedinaPermanent/HardWiredapplicationandthevehiclewillnotbe

usedforsometime,itisbesttoleavethechargerconnectedtomainspower(turned‘On’)

so that it can maintain the battery fully charged.

Ensureanymodificationtothe240Vmainsleadiscarriedoutbyaqualifiedperson

andthatconnectiontosupplymainsisinaccordancewithNationalwiringrules.

Inline fuse Ring terminal
