6
1.5 Specication
MODEL PM100J
ELECTRICAL SPECIFICATIONS
Mains
Nominal input voltage (V) 240±10%VAC 50/60Hz
Power factor 0.95
Input current at full load 2.5A
Battery
Vehicle battery 12VDC
Vehicle battery voltage range 12.8-16VDC
House battery 12VDC
House battery voltage range 10.5-16VDC
Voltage Sensitive Relay
Relay specication 12Vdc 60A Continuous, Peak current 100A, 30min
Connect voltage 13.4V (Lead Acid) / 13.7V (Lithium)
Connection delay time 10 sec
Disconnect voltage 12.8V (Lead Acid) / 13.3V & <2A (Lithium)
Disconnect delay time 60 sec
High voltage limit 16.0VDC
House battery charger Charge /
Power Supply switch set to OFF
Charge Algorithms 5 steps, soft start, bulk, absorption, oat, recycle
Battery type AGM, GEL, WET, LiFePO4
Start Voltage 2VDC (lead acid), 0VDC (lithium)
Bulk current 30A
Absorption Voltage 14.1/14.4/14.4/14.7VDC (Gel/AGM/LFP/Wet)
Float voltage 13.5/13.5/13.5/13.8VDC (Gel/AGM/LFP/Wet)
Power Supply Mode
AC Charging
Norminal output voltage 12.8±0.2 VDC
Rated output current 35A (Continuous)
Efciency 88%
Working temperature
-40°C~+65°C
(50°C: full load; 60°C:20A; 65°C: shutdown the output)
OTHERS
Battery Disconnect (LVD)
Disconnect voltage 10.5VDC (lead acid), 11.2VDC (lithium)
Delay off time 60 sec
Reconnect voltage 11.5VDC (lead acid), 12.2VDC (lithium)
Current draw on Battery
240VAC is off, no vehicle charging 200mA
When battery disconnected by LVD 60mA
When insufcient voltage available When remote switch is turn off = 0mA
Fused outputs Rated Current 8 x 10A + 2 x 15A
Protection
Short circuit on output
Fuse protectedReverse polarity
Overload protection
Battery charger over temperature
Automatic Shutdown
Battery over voltage limits
PHYSICAL SPECIFICATIONS
Dimensions (L*W*H) 270 x 197 x 70mm
Weight (kg) 2.6kgs
Enclosure Steel Case
Battery terminals M4 Screw (16mm
2
)
Load terminals M3 Screw (4mm
2
), M3.5 Screw (6mm
2
)
Cooling Automatic fan
