H150UFC

- 1 - INTRODUCTION

1.1 TECHNICAL SPECIFICATIONS

• Input voltage: AC 220-240V 50/60 Hz

• Breaker: 230V = 9A 250V

• Heater: 1550W

• First heat-up time: 5 min (approx.)

• Coverage volume: height 5 m, width 1 m

• Max. operating time: 8 sec full output

• Liquid tank capacity: 2,4 lt

• Fluid consumption: 25ml/10sec full output

• Compatible uid: water-based Prolights uid

• Control option: DMX 512, manual, timer, wireless remote

• DMX channels: 8 channels

• Power connection: Neutrik powercon

• DMX data connection: XLR-3p IN/OUT, XLR-5p IN/OUT

• Dimensions (WxHxD): 418x295x210 mm

• Weight: 10,4 kg

MODEL H150UFC

Voltage AC 220-240V 50/60 Hz

Heater 1550W

Fluid consumption 25ml/10sec full output

Dimensions (WxHxD) 418x295x210 mm

Weight 10,4 kg

Liquid tank capacity 2,4 liter
