11
H150UFC
Number of
DMX channels
Start address
(example)
DMX Address
occupied
Next possible start
address for unit No. 1
Next possible start
address for unit No. 2
Next possible start
address for unit No. 3
8 33 33-40 41 49 57
Fig.5 - Example 8 DMX channels conguration
DMX Address: 33 DMX Address: 57DMX Address: 41 DMX Address: 49
DMX512 Controller
. . . . . . . . . . . .
