PROLiNK PRO850SFCU - Overview; Component Legend

EN 3
3. Overview
3
4
6
7
5
1
2
Legend:
LED Indication:
1
Power Switch
2
USB port
3
4 Power AC Input
5
RJ11 Ports: Modem/Fax Protection
6
Backup Outlets
• Fault LED : Red lighting
• Battery mode LED : Yellow flashing
• AC mode LED : Green lighting
7
Backup Outlets
