ProMinent Beta BT5b - Page 47

80
92 / 102
E
95 / 101
148 / 153
F
K
41 / 36
L
12.9
10 / 15
81 / 85
131.5 / 135.5
M
P_BE_0020_SW
Fig. 14: Dimensional drawing of Beta
®
BT4b/BT5b, NP material version - dimensions in mm
1000 - 1604 0708 - 0220 2504 1008 - 0420 0232
E 19 7.2 24.5 14 3.2
F 172 183 178.5 188 199
K 77 77.5 77 74 76
L 105 105.5 105 102 104.5
M Ø 70 Ø 90 Ø 70 Ø 90 Ø 110
80
92 / 102
41 / 36
10 / 15
81 / 85
131.5 / 135.5
K
L
M
43.9
E
95 / 101
F
148 / 153
P_BE_0021_SW
Fig. 15: Dimensional drawing of Beta
®
BT4b/BT5b, PP and NP material versions with self-bleeding dosing
head SEK - dimensions in mm
1604 0708 - 0220 1008 - 0232
E 19 7.5 13.5
F 170.5 182.5 188.5
K 77 74 74
L 92 105.5 89
M Ø 70 Ø 90 Ø 90
Dimensional drawing of Beta
®
b, NP
material version
Dimensional drawing of Beta
®
b, PP
and NP SEK material version
Appendix
47
