Contact loading, max.
at voltage Maximum current
30 V DC 1 A.
The diaphragm rupture sensor is an NC.
–
For safety reasons we recommend connecting to a pro‐
tective low voltage, e.g. in accordance with EN 60335-1
(SELV ).
–
The cable can be connected as required.
5–25 V DC, in accordance with Namur or DIN 60947-5-6, potential-free
design.
Data Value Unit
Nominal voltage * 8 VDC
Power consumption - active surface
uncovered
> 3 mA
Power consumption - active surface cov‐
ered
< 1 mA
Rated switching distance 1.5 mm
* Ri ~ 1 kΩ
Cable colour Polarity
blue -
brown +
14.9 Stroke sensor "Sigma"
Install the sensor according to the chapter "Installation, elec‐
trical".
For more information, see "Pacing relay" in the "Relay" chapter.
a) Contact (Standard for identity code
specification "Displacement body“: A)
a) Namur sensor (for identity code specifi‐
cation "Displacement body“: A)
a) Pacing relay (stroke sensor with ...)
(Identity code specification "Stroke
sensor": 2)
Technical data
49
