18 Liquid ends Sigma/ 2
P_SI_0024
1
5
4
5
6
2
3
Fig. 26: Liquid end Sigma/ 2 130-DN 15 and 350-DN 25 PVT
Item. Description Type 16050,
16090, 16130
Type 04350,
07120, 07220
1 Spring ** **
2 Ball * *
3 Ball seat * *
4 Diaphragm rupture sensor,
visual
1033323 1033323
5 Valve 792517* 740615*
6 Multi-layer diaphragm 1029771* 1033422*
* The items listed are included in the spare parts kit. ** Special accesso‐
ries (not included in the spare parts kit). Technical changes reserved.
Liquid end Sigma/ 2 130-DN 15 and 350-
DN 25 PVT
Liquid ends Sigma/ 2
