Spare parts kits PVT (liquid ends)
Liquid end Types 16050, 16090, 16130 Types 07120, 07220, 04350
FM 130 - DN 15 1046472 -
FM 350 - DN 25 - 1046475
Spare parts kits SST (liquid ends)
Liquid end Types 16050, 16090, 16130 Types 07120, 07220, 04350
FM 130 - DN 15 1046473 -
FM 130 - DN 15 with 2 valves com‐
plete
1046474 -
FM 65 - DN 10 - 1046476
FM 65 - DN 10 with 2 valves complete - 1046477
Material version Liquid end Suction / pressure
connector
Seals* / ball seat Balls Integrated bleed
valve or relief
valve
PVT PVDF PVDF PTFE / PVDF Ceramic / glass ** PVDF / EPDM
SST Stainless steel
1.4404
Stainless steel
1.4581
PTFE / PVDF Stainless steel
1.4404
Stainless steel /
EPDM
* Metering diaphragm is PTFE-coated; seals are PTFE composite seals
PTFE: FDA No. 21 CFR §177.1550
PVDF: FDA No. 21 CFR §177.2510
** with 07120, 07220, 04350
Ordering Information
Wetted materials – "Physiologically safety
with regard to wetted materials" design
Wear parts for Sigma/ 2
