Ultra100™ TX2 User Manual
8
Installing Driver in Existing Windows 2000 System
WARNING: If you will be moving the boot drive containing the existing
Windows 2000 operating system to the Ultra100 TX2 card, the Ultra100
TX2 driver MUST be loaded on to this hard drive while it is still attached
to your existing hard drive controller. Do not attach this drive or any
other hard drive to the Ultra100 TX2 controller card before completing this step.
After installing the Ultra100 TX2 card and rebooting your system, Windows 2000
setup will show a “New Hardware Found” dialog box. Under Windows 2000, “PCI
Mass Storage Controller” will be displayed.
1. Choose “Add New Hardware Wizard” from the list, and then press “Ente r”.
2. In the A:\ drive, insert the Ultra100 TX2 driver diskette.
3. Choose “SCSI Controller” from the hardware list that appears on screen.
4. In the “Install Drivers” dialog box, press “Have disk…”.
5. When the “Install From Disk” appears, insert the “Ultra100 TX2 Driver”
diskette in drive A:.
6. Type “A:\Win2000” in the text box. Press “Enter”.
7. Choose “Win2000 Promise Ultra100 TX2™ IDE Controller” from the list that
appears on screen, and then press the “Enter” key.
8. When the "System Settings Change" dialog box appears, remove the floppy
diskette and click on “Yes” to restart the system. Windows 2000 will then
restart for the driver installation to take effect.
Confirming Windows 2000 Installation
1. From Windows 2000, open the Control Panel from “My Computer” followed
by the System icon.
2. Choose the “Hardware” tab, and then click the “Device Manager” tab.
3. Click the “+” in front of “SCSI controllers.” Win2000 Promise Ultra100 TX2 ™
IDE Controller” should appear.
