ProSun 32/1-P - Electromagnetic Immunity Guidance

30
MARK76O0003 Rev 3
Guidance and Manufacturer’s Declaration - Electromagnetic Immunity
The ProSun Onyx Model 32/1-P is intended for use in the electromagnetic environment
speciedbelow.ThecustomerortheuseroftheProSunOnyx Model 32/1-P should
assure that it is used in such an environment.
Immunity Test IEC 60601 Test Level Compliance Test Electromagnetic
Environment - Guidance
Electrostatic discharge
(ESD) IEC 61000-4-2
±2 kV, ±4 kV & ± 8 kV for
Contact Discharge
±2 kV, ±4 kV, ±8 kV and±
15kV for Air Discharge
±2 kV, ±4 kV & ± 8 kV for
Contact Discharge
±2 kV, ±4 kV, ±8 kV and±
15kV for Air Discharge
Floors should be wood,
concrete or ceramic tile.
Ifoorsarecoveredwith
synthetic material, the
relative humidity should be
at least 30%.
Electrical fast transient/
burst IEC 61000-4-4
±2kV for power supply lines
±1kV for input/output lines
±2kV for power supply lines
±1kV for input/output lines
Mains power quality
should be that of a typical
commercial or hospital
environment.
Surge IEC 61000-4-5 AC Mains Line to Ground
±0.5kV, ±1kV and ±2kV
AC Mains Line to Line
±0.5kV and ±1kV
AC Mains Line to Ground
±0.5kV, ±1kV and ±2kV
AC Mains Line to Line
±0.5kV and ±1kV
Mains power quality
should be that of a typical
commercial or hospital
environment.
Voltage dips, short
interruptions and voltage
variations on power supply
input lines
IEC 61000-4-11
<5% UT (100% dip in UT)
for 0.5 cycles
0% UT (100% dip in UT) for
1 cycle
70% UT (30% dip in UT) for
25/30 cycles
<5% UT (100% dip in UT)
for 250/300 cycles
<5% UT (100% dip in UT)
for 0.5 cycles
0% UT (100% dip in UT) for
1 cycle
70% UT (30% dip in UT) for
25/30 cycles
<5% UT (100% dip in UT)
for 250/300 cycles
Mains power quality
should be that of a typical
commercial or hospital
environment. If the user of
the ProSun Onyx Model
32/1-P requires continued
operation during power
mains interruptions, it is
recommended that the
ProSun Onyx Model 32/1-
P be powered from an
uninterrupted power supply
or a battery.
Power frequency
(50/60Hz) magnetic
eld
IEC 61000-4-8
30 A/m 30 A/m Power frequency
magneticelds
should be at levels
characteristic of a
typical location in a
typical commercial or
hospital environment.
NOTE: UT is the a.c mains voltage prior to application of the test level.
