3.7.3 Downloading the Device EEPROM Data
Press the ‘EEPROM Data Send’ button to enter the device’s EEPROM settings.
Fill in the fields of the form, then press ‘Send’ to download the information to the device.
A progress bar will appear on the main window to show the transfer progress.
The EEPROM data has been downloaded successfully once the status window reports ‘Transfer
Completed’.
To check the current EEPROM data stored in the device, press ‘EEPROM Data Get’ in the
programming software.
