93-520-20 Issue 3.3 Page 10 of 60 CirrusPro Engineer’s Manual
Inputs: Programmable
(Reset, Disable, Gain, Isolate, External Fault, Mains Fail,
Battery Fault)
Data Retention: 200 events “Event Log”, Historic Particle Graph
Water Requirements: Distilled, replenished as required, dependent upon
environment
Note: Low ambient humidity(<50% R.H) or high ambient
temperature (>30C) conditions will increase the water usage.
Unit Operating Temperature: 32-100° F (0-37.8° C) ambient
Relative Humidity: 0-95% non-condensing ambient
Cabinet:
Pro 100 11.22” x 8.47” x 5.51” (285mm x 215mm x 140mm)
Pro 200 11.22” x 8.47” x 5.51” (285mm x 215mm x 140mm)
Pro 200+ 11.22” x 8.47” x 5.51” (285mm x 215mm x 140mm)
Pro 200D 11.22” x 8.47” x 5.51” (285mm x 215mm x 140mm)
Pro 200D+ 11.22” x 8.47” x 5.51” (285mm x 215mm x 140mm)
Pro 200DSC 17.32” x 15.15” x 5.51” (440mm x 385mm x 140mm)
Pro 200DSC+ 17.32” x 15.15” x 5.51” (440mm x 385mm x 140mm)
Air Sampling System: The piping diagram for each system will be supplied by
Protec Fire Detection (Export) or an authorized
representative. This diagram will indicate tubing size, as well
as approximate lengths to each sampling point.
Gain Settings
(Sensitivity): 1-10 (1 = Minimum, 5 = Intermediate, 10 = High)
Note: If Fire 3 is set to a Gain of 1, Fire 3 Alarm Level shall
not exceed 25%".
